9 Most Common EDI Codes

Carolyn Jackson | January 13, 2022

Standardized EDI codes, officially known as ANSI X12 document types, facilitate efficient transfers of information between business partners. Familiarity with these codes is at the center of understanding what EDI is in logistics. The American National Standards Institute (ANSI) is responsible for the standard EDI codes to define document types in North America. The various EDI document types organize information, allowing buyers and suppliers to communicate consistently so nothing gets lost in translation.

Key Takeaways:

There are 100s of EDI codes, but most companies have a few that they use consistently, including the nine examples below.
Before mastering the codes that are commonly used by specific big-box stores, it is important to learn the basic syntax and some of the most common EDI codes.
EDI standards determined by the ANSI dictate what information is included in each document.

How Are Standard EDI Codes Established?

ANSI chartered the Accredited Standards Committee (ASC) X12 to develop uniform standards for EDI in 1979. Standardized ANSI X12 document types came about as part of this effort, and now there are more than 300,000 companies using X12 EDI standards for their business transactions. Many of the big-box stores deviate slightly from ANSI standards to create their own protocols as they conduct business (creating the need for retailers to have an EDI service as well as an EDI platform), but learning the rules is still important. One might think of this as mastering proper grammar before trying to understand colloquialisms and slang, and ANSI makes the syntax rules.

Most Important EDI Codes

Companies from many industries use EDI. The complete list of ANSI X12 document types sorts by the following industry sectors:

Communications and Controls
Finance
Government
Transportation
Supply Chain
Insurance

For businesses that work with big-box stores, the most critical EDI codes typically fall into the supply chain category. That said, some document types from the transportation and finance categories are also among the most common codes used by big-box stores. Even though different EDI integrations may vary, the following standardized document types are generally the most important to learn.

EDI Code 753 - Request Routing Instructions

EDI 753 originates on the supplier side and is communicated to the buyer. The request for routing instructions facilitates situations in which the buyer controls the transportation process. This transaction type includes shipment details such as the following:

Routing control number
Pick up date, time, and location
Description of the shipment and number of products
Weight, dimensions, number of units, and other shipment details

EDI Code 754 - Routing Instructions

The routing instructions transaction normally originates on the buyer side before being sent to the seller. This authorizes a shipment during the fulfillment process and provides additional instructions. This document type generally includes the following information:

Pick up date, time, and location
Carrier and number of trailers allocated
Destination
Authorization and confirmation details

EDI Code 810 - Invoice

Also referred to as EDI 810 e, the invoice is sent to the buyer by the supplier. This accounting document type can be used to communicate transaction details. EDI 810 is for general invoices, unlike EDI 210 (motor carrier freight details and invoice) or EDI 880 (grocery products invoice).

EDI 810 e-transaction types contain traditional invoice information including the following:

Invoice number
Date
Payment amount
Buyer and seller
Product quantity and line item pricing
Taxes, fees, and additional charges
Credits or allowances
Payment terms including payment due date and payment method

EDI Code 846 - Inventory Inquiry/Advance

Many big-box stores request this inventory information from their suppliers, though the transaction type can flow in either direction. It serves as an alternative to inventory API connections or merchant portals. EDI 846 document types include information such as the following:

Date and time of inquiry
Buyer and supplier
SKUs, UPCs, or other product identification
Units of inventory
Estimated restocking dates
Notice of products that have been discontinued

EDI Code 850 - Purchase Order

Officially called EDI code 850 e by ANSI, the purchase order is often one of the first transmissions businesses send upon switching to EDI. It is a logical first step in the process of placing a single order, placing a recurring order, or updating an existing order. Purchase orders include information such as the following:

Purchase order number
Order date, shipping date, and/or delivery date
Buyer name, address, and billing information
Supplier name, address, and contact information
Shipping method
SKUs, UPCs, or other product identification
Product quantity and line item pricing
Terms of payment

EDI Code 855 - Purchase Order Acknowledgment

Labeled EDI code 855 e by ANSI, this message is the response to EDI 850. It either confirms, rejects, or requests changes to the associated EDI 850. EDI 855 is the specific response for purchase orders. This goes beyond EDI 997, which simply confirms receipt of other EDI documents. EDI 855 includes the following:

Seller vendor number
Key details from the corresponding EDI 850
Errors from or required changes to the original EDI 850

EDI Code 856 - Ship Notice/Manifest

The ship notice/manifest is also known as the Advance Shipping Notice (ASN). It originates from the shipper and contains the following information for the receiver:

Shipment number
Purchase order number
Shipping date and expected delivery date
Shipping addresses and tracking details
Carrier information
Item description and quantity

EDI Code 860 - Purchase Order Change Request - Buyer Initiated

Referred to as EDI code 860 e by ANSI, this document type gives notice that the buyer needs to make changes to the previously transmitted EDI 850. The following information is provided to communicate changes:

Purchase order number
Buyer and seller
Item description and quantity
Changes to the order, including any of the following

Quantity
Price
Product
Schedule

Reasons for all changes

EDI Code 997 - Functional Acknowledgment

Officially EDI 997 e per ANSI, this is a confirmation of receipt of EDI documents. It includes the transaction code of the EDI received as well as a designation of Accepted, Accepted With Errors, or Rejected. If the original EDI was not accepted, EDI 997 includes a list of all offending elements.

Complete List of EDI Codes

Along with learning key EDI terms, mastering EDI requires consummate knowledge of the many document types and their associated codes. The list above covers some of the most important codes required to do business with big-box stores, though there may be situations in which others are required as well. The following tables capture the most updated list from ANSI (as of November 2021) in numerical order.

Designation	Meaning
b	In ballot
d	In development
e	DoD EC Program Office execution
*	Has Government Implementation Convention

Document Type	Meaning	Industry
EDI 100	Insurance Plan Description	Insurance
EDI 101	Name and Address Lists	Supply Chain
EDI 102	Associated Data	Communications and Controls
EDI 103	Abandoned Property Filings	Government
EDI 104	Air Shipment Information	Transportation
EDI 105	Business Entity Filings	Government
EDI 106	Motor Carrier Rate Proposal	Transportation
EDI 107	Request for Motor Carrier Rate Proposal	Transportation
EDI 108	Response to a Motor Carrier Rate Proposal	Transportation
EDI 109	Vessel Content Details	Transportation
EDI 110	Air Freight Details and Invoice	Transportation
EDI 111	Individual Insurance Policy and Client Information	Insurance
EDI 112	Property Damage Report	Insurance
EDI 113	Election Campaign and Lobbyist Reporting	Government
EDI 120	Vehicle Shipping Order	Transportation
EDI 121	Vehicle Service	Transportation
EDI 124	Vehicle Damage	Insurance
EDI 125	Multilevel Railcar Load Details	Transportation
EDI 126	Vehicle Application Advice	Transportation
EDI 127	Vehicle Baying Order	Transportation
EDI 128	Dealer Information	Transportation
EDI 129	Vehicle Carrier Rate Update	Transportation
EDI 130	Student Educational Record (Transcript)	Finance
EDI 131	Student Educational Record (Transcript)Acknowledgment	Finance
EDI 132	Human Resource Information	Finance
EDI 133	Educational Institution Record	Finance
EDI 135	Student Loan Application	Finance
EDI 138	Educational Testing and Prospect Request and Report	Finance
EDI 139	Student Loan Guarantee Result	Finance
EDI 140 *	Product Registration	Supply Chain
EDI 141	Product Service Claim Response	Supply Chain
EDI 142	Product Service Claim	Supply Chain
EDI 143	Product Service Notification	Supply Chain
EDI 144	Student Loan Transfer and Status Verification	Finance
EDI 146	Request for Student Educational Record (Transcript)	Finance
EDI 147	Response to Request for Student Educational Record (Transcript)	Finance
EDI 148	Report of Injury, Illness or Incident	Insurance
EDI 149 d	Notice of Tax Adjustment or Assessment	Government
EDI 150	Tax Rate Notification	Government
EDI 151	Electronic Filing of Tax Return Data Acknowledgment	Government
EDI 152	Statistical Government Information	Government
EDI 154	Uniform Commercial Code Filing	Government
EDI 155 d	Credit Report	Finance
EDI 157	Notice of Power of Attorney	Government
EDI 158	Tax Jurisdiction Sourcing	Government
EDI 159 b	Motion Picture Booking Confirmation	Supply Chain
EDI 160 d	Transportation Automatic Equipment Identification	Transportation
EDI 161	Train Sheet	Transportation
EDI 163 d	Appointment Schedule Information	Transportation
EDI 170	Revenue Receipts Statement	Supply Chain
EDI 175	Court Notice	Government
EDI 176 *	Court Submission	Government
EDI 180 *	Return Merchandise Authorization and Notification	Supply Chain
EDI 185	Royalty Regulatory Report	Government
EDI 186	Laboratory Reporting	Insurance
EDI 187 d	Request/Response to Request for Educational Course Catalog	Insurance
EDI 188 b	Educational Course Catalog	Finance
EDI 189 b	Application for Admission to Educational Institutions	Finance
EDI 190	Student Enrollment Verification	Finance
EDI 191	Student Loan Pre-Claims and Claims	Finance
EDI 194 d	Grant or Assistance Application	Government
EDI 195	Federal Communications Commission (FCC) License Application	Government
EDI 196 *	Contractor Cost Data Reporting	Government
EDI 197 d	Real Estate Title Evidence	Finance
EDI 198 d	Loan Verification Information	Finance
EDI 199 d	Mortgage Settlement Information	Finance
EDI 200	Mortgage Credit Report	Finance
EDI 201	Residential Loan Application	Finance
EDI 202	Secondary Mortgage Market Loan Delivery	Finance
EDI 203	Secondary Mortgage Market Investor Report	Finance
EDI 204	Motor Carrier Shipment Information	Transportation
EDI 205 d	Mortgage Note	Finance
EDI 206 d	Real Estate Mortgage Inspection Request	Finance
EDI 210	Motor Carrier Freight Details and Invoice	Transportation
EDI 211	Motor Carrier Bill of Loading	Transportation
EDI 212	Motor Carrier Delivery Trailer Manifest	Transportation
EDI 213	Motor Carrier Shipment Status Inquiry	Transportation
EDI 214	Transportation Carrier Shipment Status Message	Transportation
EDI 215	Motor Carrier Pick-up Manifest	Transportation
EDI 216	Motor Carrier Shipment Pickup Notification	Transportation
EDI 217	Motor Carrier Loading and Route Guide	Transportation
EDI 219	Logistics Service Request	Transportation
EDI 220	Logistics Service Response	Transportation
EDI 222	Cartage Work Assignment	Transportation
EDI 223	Consolidators Freight Bill and Invoice	Transportation
EDI 224	Motor Carrier Summary Freight Bill Manifest	Transportation
EDI 225	Response to a Cartage Work Assignment	Transportation
EDI 227	Trailer Usage Report	Transportation
EDI 228	Equipment Inspection Report	Transportation
EDI 240	Motor Carrier Package Status	Transportation
EDI 242	Data Status Tracking	Communications and Controls
EDI 244 d	Product Source Information	Supply Chain
EDI 245	Real Estate Tax Service Response	Finance
EDI 248	Account Assignment/ Inquiry and Service/ Status	Finance
EDI 250	Purchase Order Shipment Management Document	Transportation
EDI 251 *	Pricing Support	Government
EDI 252	Insurance Producer Administration	Insurance
EDI 255b	Insurance Underwriting Information Services	Insurance
EDI 256d	Periodic Annuity Compensation	Insurance
EDI 259 d	Error Reporting Immediate Response	Finance
EDI 260	Application for Mortgage Insurance Benefits	Finance
EDI 261 b	Residential Appraisal Request	Finance
EDI 262	Residential Appraisal Report	Finance
EDI 263	Residential Mortgage Insurance Application Response	Finance
EDI 264	Mortgage Loan Default Status	Finance
EDI 265	Real Estate Title Insurance Services Order	Finance
EDI 266	Mortgage Record Change	Finance
EDI 267	Individual Life, Annuity, and Disability Application	Insurance
EDI 268d	Annuity Account Activity	Insurance
EDI 269	Health Care Benefit Coordination Verification	Insurance
EDI 270	Health Care Eligibility/Benefit Inquiry	Insurance
EDI 271	Health Care Eligibility/Benefit Information	Insurance
EDI 272	Property and Casualty Loss Notification	Insurance
EDI 273b	Insurance/Annuity Application Status	Insurance
EDI 274	Healthcare Provider Information	Insurance
EDI 275b	Patient Information	Insurance
EDI 276	Health Care Claim Status Request	Insurance
EDI 277	Health Care Claim Status Notification	Insurance
EDI 278	Health Care Service Review Information	Insurance
EDI 280 d	Voter Registration Information	Government
EDI 283	Tax or Fee Exemption Notice	Government
EDI 284	Commercial Vehicle Safety Reports	Government
EDI 285	Commercial Vehicle Safety and Credentials Information Exchange	Government
EDI 286	Commercial Vehicle Credentials	Government
EDI 288	Wage Determination	Government
EDI 290	Cooperative Advertising Agreements	Supply Chain
EDI 300	Reservation (Booking Request) (Ocean)	Transportation
EDI 301	Confirmation (Ocean)	Transportation
EDI 303	Booking Cancellation (Ocean)	Transportation
EDI 304	Shipping Instructions	Transportation
EDI 309	U.S. Customs Manifest	Transportation
EDI 310	Freight Receipt and Invoice (Ocean)	Transportation
EDI 311	Canadian Customs Information	Transportation
EDI 312	Arrival Notice (Ocean)	Transportation
EDI 313	Shipment Status Inquiry (Ocean)	Transportation
EDI 315	Status Details (Ocean)	Transportation
EDI 317	Delivery/Pickup Order	Transportation
EDI 319	Terminal Information	Transportation
EDI 322	Terminal Operations and Intermodal Ramp Activity	Transportation
EDI 323	Vessel Schedule and Itinerary (Ocean)	Transportation
EDI 324	Vessel Stow Plan (Ocean)	Transportation
EDI 325	Consolidation of Goods in Container	Transportation
EDI 326	Consignment Summary List	Transportation
EDI 350	U.S. Customs Release Information	Transportation
EDI 352	U.S. Customs Carrier General Order Status	Transportation
EDI 353	U.S. Customs Events Advisory Details	Transportation
EDI 354	U.S. Customs Automated Manifest Archive Status	Transportation
EDI 355	U.S. Customs Manifest Acceptance/Rejection	Transportation
EDI 356	U.S. Customs Permit to Transfer Request	Transportation
EDI 357	U.S. Customs In-Bond Information	Transportation
EDI 358	U.S. Customs Consist Information	Transportation
EDI 361	Carrier Interchange Agreement (Ocean)	Transportation
EDI 362	Cargo Insurance Advice of Shipment	Insurance
EDI 404	Rail Carrier Shipment Information	Transportation
EDI 410	Rail Carrier Freight Details And Invoice	Transportation
EDI 412 d	Trailer/Container Repair Billing	Transportation
EDI 414	Rail Car-hire Settlements	Transportation
EDI 417	Rail Carrier Waybill Interchange	Transportation
EDI 418	Rail Advance Interchange Consist	Transportation
EDI 419	Advance Car Disposition	Transportation
EDI 420	Car Handling Information	Transportation
EDI 421	Estimated Time of Arrival and Car Scheduling	Transportation
EDI 422	Shipper’s Car Order	Transportation
EDI 423	Rail Industrial Switch List	Transportation
EDI 425	Rail Waybill Request	Transportation
EDI 426	Rail Revenue Waybill	Transportation
EDI 429	Railroad Retirement Activity	Transportation
EDI 431	Railroad Station Master File	Transportation
EDI 432	Rail Deprescription	Transportation
EDI 433	Railroad Reciprocal Switch File	Transportation
EDI 435	Standard Transportation Commodity Code Master	Transportation
EDI 436 b	Locomotive Information	Transportation
EDI 440	Shipment Weights	Transportation
EDI 451	Railroad Event Report	Transportation
EDI 452	Railroad Problem Log Inquiry or Advice	Transportation
EDI 453	Railroad Service Commitment Advice	Transportation
EDI 455	Railroad Parameter Trace Registration	Transportation
EDI 456	Railroad Equipment Inquiry or Advice	Transportation
EDI 460 d	Price Distribution or Response Format	Transportation
EDI 463 d	Rail Rate Reply	Transportation
EDI 466	Rate Request	Transportation
EDI 468	Rate Docket Journal Log	Transportation
EDI 475	Rail Route File Maintenance	Transportation
EDI 485	Rate making Action	Transportation
EDI 486 d	Rate Docket Expiration	Transportation
EDI 490	Rate Group Definition	Transportation
EDI 492	Miscellaneous Rates	Transportation
EDI 494	Scale Rate Table	Transportation
EDI 500	Medical Event Reporting	Government
EDI 501	Vendor Performance Review	Government
EDI 503 *	Pricing History	Supply Chain
EDI 504 *	Clauses and Provisions	Supply Chain
EDI 511 *	Requisition	Government
EDI 517 *	Material Obligation Validation	Government
EDI 527 *	Material Due-In and Receipt	Government
EDI 536 *	Logistics Reassignment	Government
EDI 561 *	Contract Abstract	Government
EDI 567 *	Contract Completion Status	Government
EDI 568 *	Contract Payment Management Report	Government
EDI 601	Shipper’s Export Declaration	Transportation
EDI 620	Excavation Communication	Supply Chain
EDI 625	Well Information	Supply Chain
EDI 715 b	Intermodal Group Loading Plan	Transportation
EDI 753	Request for Routing Instructions	Supply Chain
EDI 754	Routing Instructions	Supply Chain
EDI 805 *	Contract Pricing Proposal	Government
EDI 806	Project Schedule Reporting	Government
EDI 810 e	Invoice	Finance
EDI 811 *	Consolidated Service Invoice/Statement	Finance
EDI 812 *	Credit/Debit Adjustment	Finance
EDI 813	Electronic Filing of Tax Return Data	Government
EDI 814	General Request, Response, or Confirmation	Finance
EDI 815	Cryptographic Service Message	Communications and Controls
EDI 816	Organizational Relationships	Supply Chain
EDI 818	Commission Sales Report	Supply Chain
EDI 819	Operating Expense Statement	Finance
EDI 820 *	Payment Order/Remittance Advice	Finance
EDI 821	Financial Information Reporting	Finance
EDI 822	Customer Account Analysis	Finance
EDI 823	Lockbox	Finance
EDI 824 e	Application Advice	Finance
EDI 826	Tax Information Reporting	Government
EDI 827	Financial Payment Return Order/Return Notice	Finance
EDI 828	Debit Authorization	Finance
EDI 829	Payment Cancellation Request	Finance
EDI 830	Planning Schedule with Release Capability	Supply Chain
EDI 831	Application Control Totals	Finance
EDI 832 e	Price/Sales Catalog	Supply Chain
EDI 833	Mortgage Credit Report Order	Finance
EDI 834	Benefit Enrollment and Maintenance	Insurance
EDI 835	Health Care Claim Payment/Advice	Insurance
EDI 836 e	Procurement Notices	Government
EDI 837	Health Care Claim	Insurance
EDI 838 e	Business Partner Profile	Government
EDI 839	Project Cost Reporting	Government
EDI 840 e	Request for Quotation	Supply Chain
EDI 841 e	Specifications/Technical Information	Supply Chain
EDI 842 e	Nonconformance Report	Supply Chain
EDI 843 e	Response to Request for Quotation	Supply Chain
EDI 844	Product Transfer Account Adjustment	Finance
EDI 845	Price Authorization Acknowledgment/Status	Supply Chain
EDI 846	Inventory Inquiry/Advance	Supply Chain
EDI 847	Material Claim	Supply Chain
EDI 848 *	Material Safety Data Sheet	Supply Chain
EDI 849	Response to Product Transfer Account Adjustment	Finance
EDI 850 e	Purchase Order	Supply Chain
EDI 851 *	Asset Schedule	Supply Chain
EDI 852	Product Activity Data	Supply Chain
EDI 853	Routing and Carrier Instruction	Supply Chain
EDI 854	Shipment Delivery Discrepancy Information	Transportation
EDI 855 e	Purchase Order Acknowledgment	Supply Chain
EDI 856	Ship Notice/Manifest	Supply Chain
EDI 857	Shipment and Billing Notice	Supply Chain
EDI 858 *	Shipment Information	Transportation
EDI 859 *	Freight Invoice	Transportation
EDI 860 e	Purchase Order Change Request – Buyer Initiated	Supply Chain
EDI 861	Receiving Advice/Acceptance Certificate	Supply Chain
EDI 862	Shipping Schedule	Supply Chain
EDI 863 *	Report of Test Results	Supply Chain
EDI 864	Text Message	Communications and Controls
EDI 865 e	Purchase Order Change Acknowledgment/Request – Seller Initiated	Supply Chain
EDI 866	Production Sequence	Supply Chain
EDI 867	Product Transfer and Resale Report	Supply Chain
EDI 868	Electronic Form Structure	Communications and Controls
EDI 869	Order Status Inquiry	Supply Chain
EDI 870	Order Status Report	Supply Chain
EDI 872	Residential Mortgage Insurance Application	Finance
EDI 873	Commodity Movement Services	Supply Chain
EDI 874	Commodity Movement Services Response	Supply Chain
EDI 875	Grocery Products Purchase Order	Supply Chain
EDI 876	Grocery Products Purchase Order Change	Supply Chain
EDI 877 d	Manufacturer Coupon Family Code Structure	Supply Chain
EDI 878	Product Authorization/De-Authorization	Supply Chain
EDI 879	Price Change	Supply Chain
EDI 880	Grocery Products Invoice	Finance
EDI 881	Manufacturer Coupon Redemption Detail	Supply Chain
EDI 882	Direct Store Delivery Summary Information	Supply Chain
EDI 883	Market Development Fund Allocation	Supply Chain
EDI 884	Market Development Fund Settlement	Supply Chain
EDI 885	Store Characteristics	Supply Chain
EDI 886	Customer Call Reporting	Supply Chain
EDI 887 b	Coupon Notification	Supply Chain
EDI 888	Item Maintenance	Supply Chain
EDI 889	Promotion Announcement	Supply Chain
EDI 891	Deduction Research Report	Supply Chain
EDI 893	Item Information Request	Supply Chain
EDI 894	Delivery/Return Base Record	Supply Chain
EDI 895	Delivery/Return Acknowledgment or Adjustment	Supply Chain
EDI 896	Product Dimension Maintenance	Supply Chain
EDI 920	Loss or Damage Claim – General Commodities	Transportation
EDI 924	Loss or Damage Claim – Motor Vehicle	Transportation
EDI 925	Claim Tracer	Transportation
EDI 926	Claim Status Report and Tracer Reply	Transportation
EDI 928 *	Automotive Inspection Detail	Transportation
EDI 940	Warehouse Shipping Order	Supply Chain
EDI 943	Warehouse Stock Transfer Shipment Advice	Supply Chain
EDI 944	Warehouse Stock Transfer Receipt Advice	Supply Chain
EDI 945	Warehouse Shipping Advice	Supply Chain
EDI 947	Warehouse Inventory Adjustment Advice	Supply Chain
EDI 980	Functional Group Totals	Transportation
EDI 990	Response to a Load Tender	Transportation
EDI 993	Secured Receipt or Acknowledgment	Communications and Controls
EDI 996	File Transfer	Government
EDI 997 e	Functional Acknowledgment	Communications and Controls
EDI 998	Set Cancellation	Transportation
EDI 999	Implementation Acknowledgement	Communications and Controls

EDI wms Technology Integrations Warehouse Documents Featured EDI Epic Electronic Data Interchange (EDI) EDI Code
